General
Device Interfaces
• 802.11n/g Wireless LAN • Reset Button
• 10/100 Fast Ethernet Port • WPS Button
LEDs
• Status / WPS
• 3 segment Wi-Fi signal strength indicator
Standards
• IEEE 802.11n • IEEE 802.3u
• IEEE 802.11g
Antennas
• Two external antennas
PlugType
• Region dependent
Functionality
WirelessSecurity
• Wi-Fi Protected Access (WPA / WPA2) • WPS (PBC)
Advanced Features
• D-Link One-Touch Extender Setup
Device Management
• Supports QRS Mobile app for iPhone ,iPad, iPodtouch, and Android mobile devices
• WebUI
Physical
Dimensions
• 97.9 x 50.7 x 48.7 mm
Weight
• 97 grams
Power
• Input: 110 to 240 VAC, 50/60 Hz
Temperature
• Operating: 0 to 40°C • Storage:- 20 to 70°C
Humidity
• Operating: 10% to 90% non-condensing • Storage: 5% to 90% non-condensing
